Tao Motor is the leader in proving family affordable experiences. The ATA125D and D-R utility have been a long-time staple in the Tao Motor ATV line up. Tao Motor designs, manufacturers and tests its ATVs. We hope that we can provide encouragement for Off-road passion and give our consumers the confidence that anyone has the opportunity to join the Powersports family.
Specifications
| Engine | |
|---|---|
| Engine Type | 107cc, Air Cooled, 4-Stroke, single cylinder, automatic |
| Start Type | Electric Start |
| Transmission | Chain Drive |
| Engine Gear | D-N-R |
| Shift Gear | Hand |
| Max Torque | 6.5N.m/5000-5500r/min |
| Ignition | CDI |
| Fuel Tank Capacity | 1.1 Gallons |
| Chassis | |
|---|---|
| Front Hand Brake | Drum |
| Rear Foot Brake | Hydraulic Disc |
| Tire Front | 16 x 8 7 |
| Tire Rear | 16 x 8 7 |
| Front Suspension | 10.8 inches |
| Rear Suspension | 11 inches |
| Remote Control | Yes |
| Speed Limiter | Yes |
| Engine kill switch | Yes |
| Battery | 12V/4Ah |
| Wheelbase | 33.27 inches |
| Dimension | |
|---|---|
| G.W | 235 LBS |
| N.W | 210 LBS |
| Max Loading | 132 LBS |
| Carton Size | 51 x 30 24 inches |
| Seat Height | 24.81 inches |
| Ground Clearance | 3.55 inches |
